诊断和测试压力高压软管概览
Diagnostic and Calibration Pressure hose overview
-0.1-6MPa (-1~ +60bar)
1100P04 00 (Transpaency) / 1100P04 01(Black) / 1100P 04 02 Green 1100P 04 03 Red 1100P04 04 Blue 1100P04 05 Yellow 1100P 04 06 Grey LP: 745
1100P03 00 18 1100P03 04 18 LP: 510
Standard Length ： 1500mm
Out Diameter ： 4mm X 2mm
Medium： Noncorrosive Gases
Thread Style： M20x1.5 Female , M20x1.5 QCD Male
-0.1-40Mpa (-1~ +400bar ) / -0.1-63Mpa (-1~ +630bar )
2020N-012V30 / 2020N-012v50 ( V50 no Recommend for diagnostic application ) BLACK
2mm, 5/64 , 4.9mm 40Mpa ,20mm LP:78 / 2mm 5/64, 4.9 ,63Mpa, 20mm LP:79
-0.1-120Mpa (-1~ +1200bar )
2240D-025V32 BLUE Two Spiral layers
4.0mm, 7.7mm , 120Mpa, 75mm 0.10Kg/m LP: 197.00
-0.1-220Mpa (-1~ +2200bar )
2440D-025V32 BLUE Four Spiral layers
3.9mm, 10.4mm , 220Mpa（550MPa）, 100mm, 0.21Kg/m LP: 415.00
Advace Use Left Thread Style
-0.1-280Mpa (-1~ +2800bar )
2640D-025V32 BLUE Six Sprial layers of Max
3.9mm ,12.0mm ,280Mpa( 700Mpa), 140mm, 0.29Kg/m LP: 1057.00
-0.1-300Mpa (-1~ +3000bar )
2740D-025V16 YELLOW Six Sprial layers of Max
4.0mm, 12.0mm , 300Mpa( 780Mpa), 120mm, 0.40Kg/m LP : 795.00
Advace Use Left Thread Style
-0.1-400Mpa (-1~ +4000bar )
2840D-03V34 RED Eight Spiral layers of maximum
4.5mm, 15.0mm , 400Mpa( 800Mpa), 200mm, 0.66Kg/m LP: 1365.00
Advace Use Left Thread Style
